Description
6 Mode white and amber light bar
Dual-colour light bar with switchable steady and flashing modes.
Available configurations
Compact two-light packages: 3-inch standard (ZD000650), 3-inch embedded (ZD000656), 4-inch (ZD000647) and 7-inch (ZD000646). Each includes one mode-control wiring harness. The single light-bar configurations are listed below. Select an available option above to see its price.
- Straight / 22"-120W
- Straight / 30"-180W
- Curved / 42"-240W
- Curved / 50"-288W
- Straight / 42"-240W
- Straight / 50"-288W
Select the required configuration above. The price and photo follow the selection.
Six lighting modes
- White
- Amber
- White and amber
- White strobe
- Amber strobe
- White and amber strobe
Use the MODE button on the supplied harness to change modes. The controller remembers the last setting; holding the switch for more than three seconds returns it to white.
Specifications by configuration
| Configuration | Rated power | Rated output | With brackets (inches) | Without brackets (inches) |
|---|---|---|---|---|
| 22 inch straight | 120 W | 12000 lm | 24.2 × 4.92 × 3.35 | 21.1 × 3.15 × 3.35 |
| 30 inch straight | 180 W | 18000 lm | 32 × 4.92 × 3.35 | 29.1 × 3.15 × 3.35 |
| 42 inch curved | 240 W | 24000 lm | 44.7 × 4.92 × 3.35 | 41.7 × 3.15 × 3.35 |
| 50 inch curved | 288 W | 28800 lm | 52 × 4.92 × 3.35 | 49.6 × 3.15 × 3.35 |
| 42 inch straight | 240 W | 24000 lm | 44.7 × 4.92 × 3.35 | 41.7 × 3.15 × 3.35 |
| 50 inch straight | 288 W | 28800 lm | 52 × 4.92 × 3.35 | 49.6 × 3.15 × 3.35 |
Specifications
| Specification | Details |
|---|---|
| Beam | White spot and amber flood combination |
| LED type | 3030 |
| Light colour | 6000 K white / 3500 K amber |
| Voltage | 9–32 V |
| Protection | IP68 |
| Housing | Black die-cast aluminium |
| Brackets | Stainless steel |
| Operating temperature | −40 to +85 °C |
Package contents
- 3-inch standard, 3-inch embedded, 4-inch and 7-inch options: 2 lights per package
- 22-inch straight, 30-inch straight, 42-inch curved and 50-inch curved options: 1 light bar per package
- 1 × mode-control wiring harness
Order quantity
Quantity 1 orders one complete package in the selected configuration. Increase the order quantity to buy additional packages.
Fitment help
Contact TerraForge4x4 at info@terraforge4x4.com with your vehicle model, year and mounting position.
Road-use notice
For off-road use unless applicable road approval is explicitly documented. Check local regulations before use on public roads.
