Description
Choose your length
Select the required length before adding this product to your cart.
Specifications by length
| Length | Power | LED chips | Rated light output | Distance at 1 lux |
|---|---|---|---|---|
| 12 inch | 100 W | KW3 × 2 + P8 × 16 | 12,000 lm | 378 m |
| 22 inch | 180 W | KW3 × 2 + P8 × 32 | 22,000 lm | 509 m |
| 32 inch | 270 W | KW3 × 3 + P8 × 48 | 33,000 lm | 718 m |
| 42 inch | 360 W | KW3 × 4 + P8 × 64 | 44,000 lm | 927 m |
| 52 inch | 450 W | KW3 × 5 + P8 × 80 | 55,000 lm | 1345 m |
General specifications
- Input voltage: 10–30 V
- LED type: KW3 + P8
- Beam: spot and flood combination with 5D projectors
- Color temperature: 6500 K; white light
- Ingress protection: IP68
- Black aluminum housing
Features
A central projector and side reflectors combine focused distance lighting with wider illumination. The aluminum housing supports heat dissipation; adjustable mounting allows the beam angle to be set during installation.
Fitment
Check dimensions, mounting position and clearance for your vehicle before ordering.
Package included
- 1 × LED light bar
- 1 × DT wiring harness
Order quantity
Quantity 1 means one complete package as listed above, containing one light bar. Increase the cart quantity to order multiple packages.
Fitment help
Contact TerraForge4x4 at info@terraforge4x4.com with your vehicle model, year and mounting position.
Road-use notice
For off-road use unless applicable road approval is explicitly documented. Check local regulations before use on public roads.
